MITOMI device design files


PF4k devices

These devices contain about 4000 different chambers, with 2 devices arranged per wafer.  Due to the large size of these devices, they are somewhat tricky to fabricate - if it's possible to get away with 1500 chambers, we suggest using the PC1k device designs (linked below).


PC1k devices

These devices contain about 1500 different chambers, with 5 devices arranged per wafer.  The chambers are arranged in 28 rows of 56 chambers each, with a pitch of 321 between rows and a pitch of 643 between chambers.


PS1.8K devices

These devices contain 1792 chambers in a 32x56 grid (NOTE: no longer compatible with microarray pins). The standard PS1.8k device mirrors PC1k in operation.

PS4block, PS8block

These multi-block devices contain 4 or 8 “cores” respectively to allow for parallel flow of distinct substrates to different parts of the chip.


Spectrally encoded bead device design files


Serpentine channel devices

These devices are designed to flow spectrally encoded beads into a linear serpentine array for imaging.  The imaging channel is about 55 microns wide by 55 microns tall with a sieve valve at the end, so it can be used to trap anything of around that size.  There are 3 outputs at the end, which can be used for rudimentary object sorting.


AZ50 XT valve test device design files


AZ50 XT valve height test devices

These devices contain a series of rounded valves ranging from 50 to 250 um wide and from 150 to 1225 um in length, and can be used to optimize rounded photoresist fabrication protocols.
